◇ Sony Ultra-HD 4K back illuminated and stacked 1/2.3” sensor
◇ Crisply-detail, low noise 4K video
◇ Interchangeable M12, M12 AF, CS lens
◇ Built-in tally light PVW/PGM in multi-camera productions
◇ Accurate auto exposure with zone option
◇ Auto, manual, color temp, one push white balance
◇ Image freeze support
◇ Simultaneous 4K HDMI and 3G SDI outputs with embedded audio
◇ Up to 4K30 hardware video encoder
◇ H.264 HP/MP/BP or H.265/HEVC MP codec
◇ NDI® | HX3 support with better quality and very smallest delay
◇ Up to 50mbps bitrate, high bandwidth video stream for best quality
◇ NDI® | HX, RTSP, SRT, RTMP(s) steaming up to 4K30
◇ Low latency SRT streaming
◇ Direct standalone streaming to CDN like YouTube, no PC required
◇ Video scale down, Vertical/Portrait crop and rotation streaming support
◇ Simultaneous live out in different RTMP SRT RTSP and multiple CDN
◇ Adaptive AAC audio for both embedded audio and analog
◇ Analog stereo line in audio input
◇ IP VISCA control, NDI® and Web control
◇ Simple setup and configuration via login protected web interface
◇ Comprehensive control via by PC, smartphone, iPad, Controller and Panel
◇ Live video feed to PC, phone and iPad
◇ Flexible WYSIWYG OSD, text, logo and stamp image overlay, user-friendly
◇ Easy access and plug-and-play installation by mDNS
◇ Automatic rotation for vertical/portrait output and encoding
◇ Multiple standard tripod mounts also for vertical/portrait video
◇ Handy and convenient USB-C, DC, or single cable PoE power
◇ RESTFUL API supported for DIY automation and system integrator
◇ With 3 standard 1/4”camera tripod mount
◇ OEM/ODM support
| Power | |
| Input | USB TYPE C, DC to USB C Adapter support
Up to 20V 0.5A, 12W and above |
| Consumption | <12W Max |
| Camera | |
| Sensor size | Sony 1/2.3”
Back-illuminated and stacked Exmor R CMOS |
| Effective Pixels | Effective Pixels |
| Electronic Shutter | AUTO, 1/25, 1/30, 1/50, 1/60, 1/90, 1/100, 1/120, 1/125, |
| Aperture/IRIS | F2.2, Default factory installed lens |
| Gamma Control | 9 options |
| Noise Reduction | 2D/3D |
| White Balance | Auto, One Push, R/B Gain, Color Temp, Lock |
| Color Temp | 3000-6500K |
| Focus | Manual for all, AF for VCM |
| Exposure | Auto, Shutter Priority, Manual |
| Gain | 0 ~ 16 steps |
| Focal Length | 7.2mm, Default factory install lens |
| Lens Mount | M12, CS Interchangeable |
| Lens Weight | <16g, for AF Camera, <10g recommended |
| Zoom Ratio | Depend on Lens. CS only |
| FOV(D/H/V) | 48.3°/42.6°/24.6°, Distortion < 1% |
| Lens | 4K 8M Pixel M12 Non-Distortion Lens
*M12 Lens shipping with camera, CS Lens not included |
| Video: | |
| Video Encoder | H.264 HP/MP/BP, H.265 MP |
| Resolution | 4K2160p25/30, 1080p25/30/50/60
1080i50/60, 720p50/60 |
| Frame Rate | 24/25/30fps, 50/60fps for 1080/720p |
| Codec | H.264/H.265 |
| Rate Control | CBR/VBR |
| Live Preview | Web, HDMI output |
| OSD | English/Chinese, WYSIWYG editor |
| Streaming | |
| Streaming Out | RTMP(s)/SRT/RTSP |
| Bit Rate | Max. 50mbits/s, adjustable |
| NDI® | NDI® | HX3/HX2/HX (NDI v5.5, upgradeable) |
| Recorder | mp4, mov |
| Main Video Stream | Up to 4K |
| Secondary Stream | Up to 720p |
| Rotation | 0/90/180/270°, native vertical streaming |
| Video | |
| HDMI Out | 1.4b, 4:2:2(YCbCr) |
| SDI Out | 3G SDI, 800mVpp, 75ohm, 4:2:2(YCbCr) |
| NDI | NDI | HX, HX2, HX3 |
| Interface: | |
| Power | 1 x USB TYPE C, PoE |
| USB | 1 x USB, Type A |
| HDMI Input | 1 x TYPE A, Receptacle, 1.4b |
| Visible | 1 x LED, Rear |
| Audio In | 1 x 3.5mm TRS Jack |
| SDI | 1 x BNC Full size |
| Network | 1 x RJ45, Gigabit, PoE |
| Tally | 2 x LED, Front |
