This 10Gb fiber extender delivers uncompressed HDMI audio and video up to 3840×2160@30Hz with a standard transmission distance of 2 km. Widely used for HD conferencing, film production, education, and digital signage.
| Specifications name | Detailed parameters | |
|
video frequency |
Support agreement | HDMI 1.4; HDCP 1.4 |
| HDMI, and the pixel bandwidth | 225 MHz, full number | |
| HDMI, the interface bandwidth | Total bandwidth of 10.2Gbps | |
| Maximum support for the resolution | 3840X 2160@30Hz and downward compatible | |
| Video interface | The HDMI-A interface | |
| The HDMI interface impedance | 100Ω | |
| HDMI length | Less than 5 m, at 1920X1080@60Hz | |
| RS232 | joggle | DB9 |
| sense | Unidirectional transmission (single fiber); bidirectional transmission (double fiber) | |
| Baud rate | Adaptive, up to 115,200 bps | |
| data bit | Eight | |
| fibre-optical | Fiber interface | External SFP module-LC interface |
| Fiber type | single mode | |
| wavelength | Single-mode mode at 1,310 nm | |
| Interface bandwidth | 10.2Gbps | |
| The maximum transmission distance is recommended | At 3,840 X 2160 @ 30 Hz;
Single-mode standard equipment: 2KM |
|
|
other |
source | Power supply adapter: DC 12V |
| maximum power dissipation | MAX 6W | |
| working temperature | -5℃ ~ +70℃ | |
| Working humidity | 5% ~ 90% | |
| Host size | 133*90*26mm | |
| defects liability period | 1 year free warranty | |
